Android Working with Layers Animation using Basic4Android - Tutorial Part 2

Submitted by donbermoy on Sunday, January 19, 2014 - 12:54.
Good day! This is my continuation of my tutorial in working with layer animation in Android using Basic4Android. The last time i created all the necessary procedures in part1 but for now I'll give you the complete code for this. Here is the complete code for this tutorial.
  1. Sub Process_Globals
  2.
  3.         Dim TimerHorse As Timer
  4.         Dim TimerBackground As Timer
  5.         Dim TimerInterval As Long
  6. End Sub
  7.
  8. Sub Globals
  9.         Dim ImageI As Int                                                               ' index of the current horse image
  10.         Dim ImageDir As Int                                                     ' direction of the horse image
  11.         Dim ImageNumber As Int                                  ' number of horse images
  12.                 ImageNumber = 8
  13.         Dim imgHorse(2, ImageNumber) As Bitmap          ' array horse image bitmaps
  14.         Dim imvBackground As ImageView  ' background ImageView
  15.         Dim imvForeground As ImageView  ' foreground ImageView
  16.         Dim cvsForeground As Canvas                     ' canvas for the foreground image
  17.         Dim rectHorse As Rect                                           ' rectangle of the horse image
  18.         Dim HorseWidth As Int                                           ' horse image width
  19.         Dim HorseHeight As Int                                  ' horse image height
  20.         Dim HorseTop As Int                                                     ' horse image top
  21.         Dim HorseLeft As Float                                  ' current left position of the horse image
  22.         Dim HorseDelta As Float                                 ' horse move per timer tick
  23.         Dim BackgroundLeft As Float                     ' current left position of the background
  24.         Dim BackgroundDelta As Float            ' background move per timer tick
  25. End Sub
  26.
  27. Sub Activity_Create(FirstTime As Boolean)
  28.         Dim i As Int
  29.
  30.         ' load the horse images
  31.         ' first index = 0 for galloping to the right
  32.         ' first index = 1 for galloping to the left
  33.         For i = 0 To ImageNumber - 1
  34.                 imgHorse(0, i).Initialize(File.DirAssets, "horse0" & i & ".png")
  35.                 imgHorse(1, i).Initialize(File.DirAssets, "horse1" & i & ".png")
  36.         Next
  37.
  38.         ' initialize variables depending on the device orientation
  39.         If Activity.Width > Activity.Height Then
  40.                 HorseDelta = 4dip
  41.                 HorseHeight = 40%y
  42.                 TimerInterval = 50
  43.         Else
  44.                 HorseDelta = 2dip
  45.                 HorseHeight = 25%y
  46.                 TimerInterval = 80
  47.         End If
  48.
  49.         ' initialize the background timer
  50.         TimerBackground.Initialize("TimerBackground", TimerInterval)
  51.
  52.         ' initialize the horse timer
  53.         ' we use two times the background timer interval
  54.         TimerHorse.Initialize("TimerHorse", TimerInterval * 2)
  55.
  56.         ' calculate the horse images size and their vertical position
  57.         HorseWidth = HorseHeight / imgHorse(0, 0).Height * imgHorse(0, 0).Width
  58.         HorseTop = 65%y - HorseHeight / 2
  59.         rectHorse.Initialize(0, HorseTop, HorseWidth, HorseTop + HorseHeight)
  60.
  61.         ' initialize the background
  62.         imvBackground.Initialize("")
  63.         Activity.AddView(imvBackground, 0, 0, 400%y, 100%y)
  64.         imvBackground.Gravity = Gravity.FILL
  65.         imvBackground.Bitmap = LoadBitmap(File.DirAssets, "Wyoming.jpg")
  66.         imvBackground.Left = 0
  67.
  68.         ' calculate BackgroundDelta
  69.         ' to have the same number of steps as for the horse
  70.         i = (100%x - HorseWidth) / HorseDelta
  71.         BackgroundDelta = -(imvBackground.Width - 100%x) / 2 / i
  72.
  73.         ' initialize the foreground
  74.         imvForeground.Initialize("")
  75.         Activity.AddView(imvForeground, 0, 0, 100%x, 100%y)
  76.
  77.         ' initialize the foreground canvas
  78.         cvsForeground.Initialize(imvForeground)
  79.
  80.         ' set the foreground to transparent
  81.         Dim rect1 As Rect
  82.         rect1.Initialize(0, 0, imvForeground.Width, imvForeground.Height)
  83.         cvsForeground.DrawRect(rect1, Colors.Transparent, True, 1)
  84. End Sub
  85.
  86. Sub Activity_Resume
  87.         Activity.Title = "Working with Layers (Animation)"
  88.
  89.         ' initialize the timers
  90.         TimerHorse.Enabled = True
  91.         TimerBackground.Enabled = True
  92.
  93.         ' set the initial values
  94.         HorseLeft = 0
  95.         BackgroundLeft = 0
  96.         ImageI = 0
  97.         ImageDir = 0
  98.
  99.         ' draw the first horse image
  100.         DrawHorse(ImageI, 10)
  101. End Sub
  102.
  103. Sub Activity_Pause (UserClosed As Boolean)
  104.         ' stop the timers
  105.         TimerHorse.Enabled = True
  106.         TimerBackground.Enabled = True
  107. End Sub
  108.
  109. Sub TimerHorse_Tick
  110.         ' increase the horse left position
  111.         HorseLeft = HorseLeft + HorseDelta
  112.
  113.         ' test if the horse reaches the right or left border
  114.         If HorseLeft >= 100%x - HorseWidth - HorseDelta OR HorseLeft <= 0 Then
  115.                 BackgroundDelta = - BackgroundDelta
  116.                 HorseDelta = - HorseDelta
  117.                 HorseLeft = HorseLeft + HorseDelta
  118.                 If ImageDir = 0 Then
  119.                         ImageDir = 1
  120.                 Else
  121.                         ImageDir = 0
  122.                         imvBackground.Left = 0
  123.                 End If
  124.         End If
  125.
  126.         ' update the horse image index
  127.         ImageI = ImageI + 1
  128.         ' reset the image index
  129.         If ImageI = ImageNumber Then
  130.                 ImageI = 0
  131.         End If
  132.
  133.         ' draw the new horse image
  134.         DrawHorse(ImageI, HorseLeft)
  135. End Sub
  136.
  137. Sub TimerBackground_Tick
  138.         ' set the background left position
  139.         BackgroundLeft = BackgroundLeft + BackgroundDelta
  140.         imvBackground.Left = BackgroundLeft
  141. End Sub
  142.
  143. Sub DrawHorse(i As Int, x As Float)
  144.         ' drawing routine for the horse image
  145.
  146.         ' erase the current horse image, draw a transparent rectangle
  147.         cvsForeground.DrawRect(rectHorse, Colors.Transparent, True, 1)
  148.
  149.         ' set the new horse image position
  150.         rectHorse.Left = x
  151.         rectHorse.Right = x + HorseWidth
  152.
  153.         ' draw the new horse image
  154.         cvsForeground.DrawBitmap(imgHorse(ImageDir, i), Null, rectHorse)
  155.
  156.         ' invalidate (update) the foreground image
  157.         imvForeground.Invalidate2(rectHorse)
  158. End Sub
